Moxa AWK-4131A-US-T

Introduction

The AWK-4131A IP68 outdoor industrial AP/bridge/clientmeets the growing need for faster data transmission speeds by supporting802.11n technology and allowing 2X2 MIMO communication with a netdata rate of up to 300 Mbps. The AWK-4131A is compliant with industrialstandards and approvals covering operating temperature, power inputvoltage, surge, ESD, and vibration. The two redundant DC power inputsincrease the reliability of the power supply, and the AWK-4131A canbe powered via PoE to make deployment easier. The AWK-4131A can operateon either the 2.4 GHz or 5 GHz bands and is backwards-compatible withexisting 802.11a/b/g deployments to future-proof your wireless investments.The Wireless add-on for the MXview network management utility visualizesthe AWK's invisible wireless connections to ensure wall-to-wall Wi-Ficonnectivity.

Advanced802.11n Industrial Wireless Solution

• 802.11a/b/g/ncompliant AP/bridge/client for flexible deployment

• Software-optimizedfor long-distance wireless communication with up to 1 km line of sightand external high-gain antenna (available only on 5 GHz)

• Supports60 clients connected concurrently

• DFSchannel support allows a wider range of 5 GHz channel selection toavoid interference from existing wireless infrastructure

Advanced Wireless Technology for Mission-critical Applications

• Seamlessroaming with client-based Turbo Roaming The Turbo Roaming recoverytime indicated herein is an average of test results documented, inoptimized conditions, across APs configured with interference-free20-MHz RF channels, WPA2-PSK security, and default Turbo Roaming parameters.The clients are configured with 3-channel roaming at 100 Kbps trafficload. Other conditions may also impact roaming performance. For moreinformation about Turbo Roaming parameter settings, refer to the productmanual. for

• AeroMagsupport for error-free setup of your industrial applications’ basicWLAN settings

• SupportsAeroLink Protection for creating a redundant wireless link (

Industrial Ruggedness

• Integrated antenna and power isolation designed to provide 500 V insulation protection against external electrical interference

• IP68-rated metal casing for complete ingress protection for any outdoor weather

• -40 to 75°C wide operating temperature models available for smooth wireless communication in harsh environments

WirelessNetwork Management With MXview Wireless

• Dynamictopology view shows the status of wireless links and connection changesat a glance

• Visual,interactive roaming playback function to review the roaming historyof clients

• Detaileddevice information and performance indicator charts for individualAP and client devices
