Moxa CCG-1510-US-T

CCG-1500 Series

CCG-1510-US-T ; Industrial private 5G 3GPP R15 cellular gateway, IP30, USA N48 band, -40 to 70°C operating temperature

Free Ground Shipping on U.S. Orders over $99 $1,318.00 ON BACKORDER Estimated Availability: 02/21/2025

Please contact us via sales@neteon.net or 888-908-3330 for other product options.

ADD TO CART

Call Us 1-888-908-3330 for Availability or Possible Alternatives

Features and Benefits

moxa-ccg-1500-series-datasheet-v1.3.pdf

Qualcomm® Snapdragon™ X55
5G-ready media converter with industrial-grade FCC/UL/NCC/JET/Telec certifications
Dual SIM slots
2 auto-sensing 10/100/1000 Mbps Ethernet ports
1 RS-232/422/485 serial port
LEDs for easy installation and maintenance
-40 to 70°C wide-temperature design

Overview Specifications Accessories

Introduction

The CCG-1500 Series is designed both as a media converterand a protocol converter. The media converter includes 5G-to-ethernetand 5G-to-serial ports, which can be used for public as well as privatenetworks. The protocol converter is mainly for Modbus TCP/RTU conversion.The 5G interface can use Modbus TCP while the serial interface canprocess Modbus RTU.

The CCG-1500is built around a Qualcomm® Snapdragon™ X55 Cortex-A7 processor thathas been optimized for use in media-conversion scenarios, and is alsowidely applicable to a variety of industrial solutions. With flexibleinterfacing options, this tiny, embedded converter is a reliable andsecure gateway for data processing at field sites as well as a usefulcommunications platform for large-scale deployments.

Wide temperature 5G-enabled modelsare available for extended temperature applications. All units arethoroughly tested in a testing chamber, guaranteeing that the 5G-enabledcomputing platforms are suitable for wide-temperature applications.
