CP-112UL Series

Moxa CP-112UL Series

2-port RS-232/422/485 Universal PCI serial boards with optional 2 kV isolation
CP-112UL Series
Free Ground Shipping on U.S. Orders over $99
VIEW MODELS
 Call Us 1-888-908-3330 for Availability or Possible Alternatives

Features and Benefits

moxa-cp-112ul-series-datasheet-v1.2.pdf
  • Over 700 kbps data throughput for top performance
  • 128-byte FIFO and on-chip H/W, S/W flow control
  • Universal PCI compatible with 3.3/5 V PCI and PCI-X
  • 921.6 kbps maximum baudrate for fast data transmission
  • Drivers provided for a broad selection of operating systems, including Windows, Linux, and UNIX
  • Easy maintenance with built-in LEDs
  • Wide-temperature model available for -40 to 85°C environments
View More
Product ID Product Description Availability Price Qty
Overview Specifications Accessories

Introduction

Moxa’s CP-112UL Series of multiport serial boards aredesigned to be used by industrial automation system integrators forlong-distance, multipoint, PC-based data acquisition applications.On-chip Automatic Data Direction Control for precision RS-485 communicationrequires precise timing control for enabling and disabling the linedriver. Moxa’s Turbo Serial Engine™ chip that powers the CP-112ULboards comes with on-chip ADDC®, which makes RS-485 as easy to useas RS-232. The boards come with 2 RS-422/485 serial ports, both ofwhich can achieve data rates up to 921.6 kbps. In RS-485 mode, theserial port can connect up to 31 daisy-chained RS-485 devices withina range of 1.2 km. For long-distance RS-485 communication, 2 kV electricalisolation protection is available to prevent equipment damage.

Drivers Provided for Windows, Linux, and UNIX

Moxa continues to support a wide variety of operatingsystems, and the CP-112UL boards are no exception. Reliable Windows,Linux, and UNIX drivers are provided for all Moxa boards, and otheroperating systems, such as WEPOS, are also supported for embeddedintegration.
