MDR Power Supply Series

MOXA MDR Power Supply Series

40/60 W slim form factor power supplies for DIN-rail mounted products
MDR Power Supply Series
VIEW MODELS
Exclusive Bulk Pricing on Select Products
Sign Up to Access.
Call Us 1-888-908-3330 for Availability or Possible Alternatives

Features and Benefits

moxa-mdr-power-supply-series-datasheet-v1.2.pdf
  • High inrush current protection
  • 24 VDC power output
  • -20 to 70°C operating temperature range
  • 85 to 264 VAC or 120 to 370 VDC input
View More

Product ID Product Description Availability Price Qty
Overview Specifications Accessories

Introduction

The MDR Power Supply Series supports inrush currentprotection of 30 A at 115 VAC and 60 A at 230 VAC. The series hasan operating temperature range of -20 to 70°C and a three year warranty,which ensures suitability for operating in harsh environments. Inaddition, the MDR Series has passed a 100% full load burn-in test,is UL/CUL listed, TÜV/CB certified, and CE marked. There are alsomodels available with output ratings from 40 W to 60 W with 24 VDCoutput.
