TAP-213 Series

Moxa TAP-213 Series

Rail onboard 802.11n IP68 wireless AP/client
TAP-213 Series
Free Ground Shipping on U.S. Orders over $99
VIEW MODELS
 Call Us 1-888-908-3330 for Availability or Possible Alternatives

Features and Benefits

moxa-tap-213-series-datasheet-v1.6.pdf
  • IEEE 802.11a/b/g/n compliant
  • Can be powered by redundant dual DC power inputs or PoE
  • QoS (WMM) and VLAN for efficient network traffic
  • Controller-based Turbo Roaming (less than 50 ms) The Turbo Roaming recovery time indicated herein is an average of test results documented, in optimized conditions, across APs configured with interference-free 20-MHz RF channels, WPA2-PSK security, and default Turbo Roaming parameters. The clients are configured with 3-channel roaming at 100 Kbps traffic load. Other conditions may also impact roaming performance. For more information about Turbo Roaming parameter settings, refer to the product manual.
  • Complies with all EN 50155 mandatory test items This product is suitable for rolling stock railway applications, as defined by the EN 50155 standard. For a more detailed statement, click here: www.moxa.com/doc/specs/EN_50155_Compliance.pdf
  • Rugged IP68-rated housing and -40 to 75°C operating temperature
  • Wireless network redundancy with AeroLink Protection
View More
Product ID Product Description Availability Price Qty
Overview Specifications Accessories

Introduction

The TAP-213 outdoor wireless AP/client is the ideal ruggedized wireless solution for railway onboard and train-to-ground applications such as CCTV and CBTC communications. The TAP-213’s dust-tight, weatherproof design is IP68-rated, allowing you to extend wireless networks to outdoor locations and critical environments. The two redundant DC power inputs increase the reliability of the power supply and the device can also be powered via PoE for easier deployment. The TAP-213 is compliant with the mandatory test items of the EN 50155 standard to ensure suitability for rolling stock applications. With many hardened industrial-grade features, the TAP-213 will provide stable and reliable wireless connectivity, especially for rail onboard environments.

Features for Critical Environments

  • IP68-rated metal housing and -40 to 75°C wide operating temperature

  • Anti-vibration M12 design with waterproof and dustproof connectors

  • PoE and dual DC power inputs

  • High-power 400 mW (max.) radio

  • Wide range power input from 24 to 110 VDC

  • Client-based Turbo Roaming handover time less than 150 ms with 3 channels and WPA2

  • Controller-based Turbo Roaming handover time (available only when used with the WAC-1001 or WAC-2004) less than 50 ms with 3 channels and WPA2

  • Multiple roaming parameters for different installation structures and antenna types
