TCF-142-S-SC-RM

Moxa TCF-142-S-SC-RM

TCF-142-RM Series
RS-232/422/485 to Fiber Optic Converter. SC Single mode. Slide-in Module
Image of TCF-142-S-SC-RM
Free Ground Shipping on U.S. Orders over $99 $534.73 ON BACKORDER Estimated Availability: 02/22/2025

Please contact us via sales@neteon.net or 888-908-3330 for other product options.

ADD TO CART
Call Us 1-888-908-3330 for Availability or Possible Alternatives

Features and Benefits

moxa-tcf-142-rm-series-datasheet-v1.0.pdf
  • Extends RS-232/422/485 transmission up to 40 km with single-mode or 5 km with multi-mode
  • 1 or 150 kilo-ohm adjustable pull high/low resistor
  • Supports ring and point-to-point transmission
View More
Overview Specifications Accessories

Introduction

The TCF-142-RM Series slide-in modules are serial-to-fiber converters that work with the TRC-190 chassis. The modules convert from the RS-232, RS-422, or RS-485 signal to a fiber-optic signal.

Automatic Baudrate Detection

The TCF-142-RM Series can automatically detect the serial baudrate. This is an extremely convenient feature. Even if a device’s baudrate is changed, the signal will still be transmitted through the media converter without any problem.
