TN-5308 Series

Moxa TN-5308 Series

EN 50155 8-port unmanaged Ethernet switches
TN-5308 Series
Free Ground Shipping on U.S. Orders over $99
VIEW MODELS
 Call Us 1-888-908-3330 for Availability or Possible Alternatives

Features and Benefits

moxa-tn-5308-series-datasheet-v2.1.pdf
  • M12 connectors and IP40 metal housing
  • Up to 8 IEEE 802.3af compliant PoE and Ethernet combo ports
  • Supports IEEE 802.3/802.3u/802.3x
  • Complies with all EN 50155 mandatory test items This product is suitable for rolling stock railway applications, as defined by the EN 50155 standard. For a more detailed statement, click here: www.moxa.com/doc/specs/EN_50155_Compliance.pdf
  • -40 to 75°C operating temperature range (-T models)
View More
Product ID Product Description Availability Price Qty
Overview Specifications Accessories

Introduction

The ToughNet TN-5308 Series M12 unmanaged Ethernetswitches are designed for industrial applications in harsh environments.TN-5308 Series switches use M12 connectors to ensure tight, robustconnections, and guarantee reliable operation against environmentaldisturbances, such as vibration and shock. The TN-5308 Series Ethernetswitches provide 8 Fast Ethernet M12 ports, support IEEE 802.3/802.3u/802/3xwith 10/100M, full/half-duplex, MDI/MDI-X auto-sensing, and providean economical solution for your industrial Ethernet network.

Models with an extendedoperating temperature range of -40 to 75°C are also available. TN-5308Ethernet switches comply with those EN 50155 requirements that makeproducts more suitable for rolling stock applications, including operatingtemperature, power input voltage, surge, ESD, and vibration, makingthe switches suitable for a variety of industrial applications. TN-5308PoE Ethernet switches provide 4 or 8 IEEE 802.3af compliant PoE ports.These switches are classified as power source equipment (PSE) andprovide up to 15.4 watts of power per port.
