UC-8200 Series

MOXA UC-8200 Series

Arm Cortex-A7 dual-core 1 GHz IIoT gateways with built-in LTE Cat. 4, 1 Mini PCIe expansion slot for a Wi-Fi module, 1 CAN port, 4 DIs, 4 DOs
UC-8200 Series
VIEW MODELS
Exclusive Bulk Pricing on Select Products
Sign Up to Access.

Features and Benefits

moxa-uc-8200-series-datasheet-v3.0.pdf moxa-uc-8200-series-datasheet-v3.3.pdf
  • Armv7 Cortex-A7 dual-core 1 GHz
  • Moxa Industrial Linux with 10-year superior long-term support
  • LTE-ready computer with Verizon/AT&T certification and industrial-grade CE/FCC/UL certifications
  • Dual SIM slots
  • 2 auto-sensing 10/100/1000 Mbps Ethernet ports
  • Integrated LTE Cat. 4 module with US/EU/APAC band support
  • 1 CAN port supports CAN 2.0A/B
  • microSD socket for storage expansion
  • IEC 62443-4-2 Security Level 2 certified
  • -40 to 85°C wide temperature range and -40 to 70°C with LTE enabled
View More

Product ID Product Description Availability Price Qty
Overview Specifications Accessories

Introduction

The UC-8200 computing platform is designed forembedded data acquisition applications. The computer comes with dualRS-232/422/485 serial ports, dual 10/100/1000 Mbps Ethernet ports,and one CAN port as well as dual Mini PCIe socket to support Wi-Fi/cellularmodules. These versatile capabilities let users efficiently adaptthe UC-8200 to a variety of complex communications solutions.

The UC-8200 is builtaround a Cortex-A7 dual core processor that has been optimized foruse in energy monitoring systems, but is widely applicable to a varietyof industrial solutions. With flexible interfacing options, this tinyembedded computer is a reliable and secure gateway for data acquisitionand processing at field sites as well as a useful communications platformfor many other large-scale deployments.

Wide temperature LTE-enabled models are availablefor extended temperature applications. All units are thoroughly testedin a testing chamber, guaranteeing that the LTE-enabled computingplatforms are suitable for wide-temperature applications.

IEC 62443-4-2 Security Level 2 Certified

The UC-8200 Series models with Moxa Industrial Linux3 (MIL3) are IEC 62443-4-2 Security Level 2 certified, making it easierfor asset owners and system integrators to integrate IIoT applicationsby providing a secure platform that has already been tested and validatedto protect IIoT data and infrastructure against cyberthreats.

IEC 62443-4-2 Security Level 2certificate:https://21577316.fs1.hubspotusercontent-na1.net/hubfs/21577316/2022%20ISA%20Website%20Redesigns/ISA%20Secure/PDFs/IEC-62443-4-2-Certified-Components/ISASecure-Moxa-UC-8200-CSA-Certificate.pdf

Appearance

UC-8210

UC-8220
