WK-71-01

UC-3400A Series

UC-3400A Wall-mounting Kit with 4 M3 screws

Free Ground Shipping on U.S. Orders over $99 $26.00 ON BACKORDER Estimated Availability: 08/02/2025

Please contact us via sales@neteon.net or 888-908-3330 for other product options.

ADD TO CART

Call Us 1-888-908-3330 for Availability or Possible Alternatives

Features and Benefits

moxa-uc-3400a-series-datasheet-v1.0.pdf

Armv8 Cortex-A53 1.4 GHz processor
Integrated 4G LTE Cat. 4 module with dual SIM and AT&T approval
Wi-Fi 6 built-in
2 auto-sensing 10/100/1000 Mbps Ethernet ports
CAN ports with 2-kV isolation protection
Moxa Industrial Linux with 10-year superior long-term support
Compliance with IEC 62443-4-2 Security Level 2 requirements
CE/FCC/UL certifications
-40 to 70°C operating temperature range

Overview Specifications Accessories

Introduction

Moxa’s UC-3400A Series computers can be used as edgegateways in the field for data pre-processing and transmission, aswell as for other embedded data-acquisition applications. The seriesincludes a diverse set of models, each supporting different wirelessoptions and protocols. The UC-3400A’s advanced heat-dissipation designmakes it suitable for use in temperatures ranging from -40 to 70°C.In fact, the Wi-Fi and LTE connections can be used simultaneouslyin both cold and hot environments, allowing you to maximize data pre-processingand transmission capabilities of your applications in harsh operatingenvironments.

TheUC-3400A is more than just a hardware solution. In order to offera better user experience with a Moxa Arm-based computer, the UC-3400Acomes equipped with Moxa Industrial Linux, a high-performance industrial-gradeLinux distribution with long-term support that is developed by Moxa.
