EDS-G4012 Series

MOXA EDS-G4012 Series

12G-port full Gigabit managed Ethernet switches with an 8 802.3bt PoE port option
EDS-G4012 Series
VIEW MODELS
Exclusive Bulk Pricing on Select Products
Sign Up to Access.

Features and Benefits

moxa-eds-g4012-series-datasheet-v1.7.pdf
  • Support for IEEE 802.3bt PoE for up to 90 W output per port
  • Increased bandwidth capabilities with fiber SFP slots supporting up to 2.5 Gbps
  • Turbo Ring and Turbo Chain (recovery time 50 ms @ 250 switches), and RSTP/STP for network redundancy
  • Wide range of power input options for flexible deployment
  • Compact and flexible housing design to fit into confined spaces
  • Supports MXstudio for easy, visualized industrial network management
  • IEC 62443-4-2 Security Level 2 certified
View More

Product ID Product Description Availability Price Qty
Overview Specifications Accessories

Introduction

The EDS-G4012Series is equipped with 12 Gigabit Ethernet ports and up to four 1Gbps or 2.5 Gbps fiber-optic ports, making it ideal for upgradingan existing network to Gigabit speed or building a new full Gigabitbackbone. Gigabit transmission speed increases bandwidth for higherperformance and transfers large amounts of triple-play services acrossa network quickly. This Series also comes with eight 10/100/1000BaseT(X)802.3af (PoE), 802.3at (PoE+), and 802.3bt-compliant Ethernet portoptions to connect high-bandwidth PoE devices.

Redundant Ethernet technologies such as TurboRing, Turbo Chain, and RSTP/STP increase the reliability of your systemand improve the availability of your network backbone. The EDS-G4012Series is designed specifically for demanding applications such asvideo and process monitoring, ITS, and DCS systems, all of which canbenefit from a scalable backbone construction.

IEC 62443-4-2 Security Level 2 Certified

EDS-(G)4000 Series models are IEC 62443-4-2 Security Level 2 certified(https://certificates.iecee.org/#/deliverables/CERT/1605016/view), helping our customers meet the requirements of secure industrialnetworks.
