EJS-04

EJS-04

EJS-04 Series
Industrial EtherCAT junction with 4 100BaseT(X) ports, dual 12/24/48 VDC power inputs, -10 to 60°C
Image of EJS-04
ADD TO CART
$236.25
Out of stock
  • Contact Us for Availability or Possible Alternatives
Exclusive Bulk Pricing on Select Products
Sign Up to Access.

Features and Benefits

moxa-ejs-04-series-datasheet-v1.1.pdf
  • 4 100BaseT(X) full-duplex RJ45 ports for multiple slave connections
  • Supports topology conversion for more flexible EtherCAT networks
  • Compact size for easy installation
  • Wide power input range with redundancy options
  • IP30-rated metal housing
  • Meets the EN 61000-6-2 and EN 61000-6-4 standards for industrial EMC applications
  • Supports DIN-rail grounding to optimize space and wiring
View More

Overview Specifications Accessories

Introduction

Moxa’s EJS-04 Series EtherCAT junctions are equipped with4 Fast Ethernet EtherCAT ports. These devices support star, line,ring, or tree topology conversion, enabling multiple EtherCAT devicesto be connected in a modular and efficient manner. The EJS Seriesfeatures a robust metal housing with high electromagnetic compatibilityto shield against environmental inference while support for multiplegrounding methods simplifies wiring and installation.

The EJS Series supports a range ofredundancy features to enhance the reliability and availability ofEtherCAT networks. Topology conversion minimizes production line interruptionsand improves troubleshooting efficiency. The dual power input designlets you connect a redundant power supply for non-stop availabilityin the event of a main power failure. Moreover, the EJS Series canbe used in redundancy topologies to provide alternative data pathsin case one data path fails, ensuring that the exchange of data isnot interrupted.

The EJS Seriesis certified for the EtherCAT Conformance Test by the EtherCAT TechnologyGroup (ETG), meaning the EJS Series integrates into your existingnetwork seamlessly, making the EJS Series ideal for use in any EtherCATapplication.
